| Technical Specifications |
| Mobile |
| Mobile module |
5G Sub-6Ghz SA 223 Mbps DL, 123 Mbps UL; 4G LTE Cat 4 – LTE 195 Mbps DL, 105 Mbps UL |
| 3GPP Release |
Release 17 RedCap |
| SIM switch |
2 SIM cards, auto-switch cases: weak signal, data limit, SMS limit, roaming, no network, network denied, data connection fail, SIM idle protection |
| Status |
IMSI, ICCID, operator, operator state, data connection state, network type, bandwidth, connected band, signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, data sent/received, LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC, and MNC |
| SMS |
SMS status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP |
| USSD |
Supports sending and reading Unstructured Supplementary Service Data messages |
| Black/White list |
Operator black/white list (by country or separate operators) |
| Multiple PDN |
Possibility to use different PDNs for multiple network access and services |
| Band management |
Band lock, Used band status display |
| SIM idle protection service |
Inactive SIM remains idle until switched, preventing unnecessary data usage |
| SIM PIN code management |
Enables setting, changing, or disabling the SIM card's PIN |
| APN |
Auto APN |
| Bridge |
Direct connection (bridge) between mobile ISP and device on LAN |
| Passthrough |
Router assigns its mobile WAN IP address to another device on LAN |
| Wireless |
| Wireless mode |
802.11b/g/n (Wi-Fi 4), Access Point (AP), Station (STA) |
| Wi-Fi security |
WPA2-Enterprise, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE; AES-CCMP, TKIP, Auto-cipher modes, client separation, EAP-TLS with PKCS#12 certificates, 802.11w PMF |
| SSID/ESSID |
SSID stealth mode and access control based on MAC address |
| Wi-Fi users |
Up to 100 simultaneous connections |
| Wireless Connectivity Features |
Wireless mesh (802.11s), fast roaming (802.11r), BSS transition management (802.11v), radio resource measurement (802.11k) |
| Wireless MAC filter |
Allowlist, blocklist |
| Wireless QR code generator |
Automatic network login upon QR code scan |
| TravelMate |
Forwards Wi-Fi hotspot landing page to connected devices |
| Ethernet |
| WAN |
1 x WAN port 10/100 Mbps, IEEE 802.3, IEEE 802.3u, IEEE 802.3az, auto MDI/MDIX |
| LAN |
3 x LAN ports, 10/100 Mbps, IEEE 802.3, IEEE 802.3u, auto MDI/MDIX |
| Network |
| Routing |
Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy-based routing |
| Network protocols |
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, WOL, VXLAN |
| VoIP passthrough support |
H.323 and SIP-ALG NAT helpers for VoIP routing |
| Connection monitoring |
Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP link inspection |
| Firewall |
Port forward, traffic rules, custom rules |
| Firewall status page |
View all firewall statistics, rules, and counters |
| Ports management |
View, enable/disable, configure auto settings, change speed |
| Network topology |
Graphical representation of connected devices |
| DHCP |
Static/dynamic allocation, DHCP relay, server configuration, static leases |
| QoS / Smart Queue Management (SQM) |
Traffic prioritisation by source, destination, service, protocol, or port |
| DDNS |
Supports over 25 providers, custom configurations available |
| DNS over HTTPS |
Secure DNS resolution via HTTPS proxy |
| Network backup |
Wi-Fi WAN, Mobile, VRRP, Wired automatic failover |
| Load balancing |
Distributes traffic across multiple WAN connections |
| Hotspot |
Captive portal, Radius authentication, SMS authorisation, user management |
| SSHFS |
Mount remote file systems via SSH |
| Port Mirroring |
Monitors and analyses network traffic on Ethernet ports |
