The Laird Connectivity FG9026 Omni-Directional Antenna 900MHz 8dBi applications are used by private organizations and government agencies around the globe.  Typical applications include land-based and marine radio and data transmissions for public sa…
SKU: ANT-LA-00001
MPN: 814-FG9026
Shipping: Calculated at Checkout
RRP: $498.63
$373.98 inc GST
($339.98 ex GST)
(You save: $124.65 )
Hurry up! Current stock:

Laird Connectivity FG9026 Omni-Directional Antenna 900MHz 8dBi

RRP: $498.63
$373.98 inc GST
($339.98 ex GST)
(You save: $124.65 )
The Laird FG9026 900 MHz omnidirectional antenna is designed for use as an LPWAN base station antenna. Covering the full 915 MHz ISM band from 902 to 928 MHz the antenna has been optimised for LPWAN IoT networks. It uses a finely tuned collinear stacked-dipole design which ensures maximum radiated efficiency and stability across the 915 MHz band. Laird's fiberglass base station antennas are collinear designs enclosed in high-density fiberglass, which is covered with a protective ultraviolet inhibiting coating. The radiating elements are made from high-efficiency copper and are carefully phased to provide maximum gain in the horizontal plane.   The mounting sleeves are tuned to eliminate RF currents from the transition line.  This results in a "cold" sleeve allowing great freedom in mounting.  This high-quality and well-focused beam provides the highest gain and best efficiency.

FEATURES:

  • Tuned specifically for 915 MHz ISM IoT LPWANs
  • Easy installation
  • Weatherproof, UV-stabilised radome
  • N Female connector
Mounting kit sold separately.



The Laird Connectivity FG9026 Omni-Directional Antenna 900MHz 8dBi applications are used by private organizations and government agencies around the globe.¬† Typical applications include land-based and marine radio and data transmissions for public safety agencies, commercial organizations, and the military.
General Information
Manufacturer: Laird Connectivity
Manufacturer Part Number: 814-FG9026
Packaging Details
Weight: 0.50 KGS
Width: 5.00 (cm)
Height: 158.00 (cm)
Depth: 5.00 (cm)
