Cambium Networks C000000L066B cnPulse Sync Generator with CambiumSYNC GPS

Cambium Networks C000000L066B cnPulse Sync Generator with CambiumSYNC GPS  is the latest GPS synchronization generation device designed specifically for Cambium Networks PMP and PTP radios. The cnPulse module is IP67 (weatherproof and supports a wide temperature range for rugged environments. The GPS receiver is highly reliable and supports both GPS and GNSS signals. There are no configuration or software settings required. cnPulse can be deployed in two alternative ways. Note that a single cnPulse can provide synchronization to two APs by leveraging mode 1 on the first ODU and mode 2 on the second ODU.



Cambium Networks C000000L066B cnPulse Sync Generator with CambiumSYNC GPS Mode 1: AUX Serial mode (uses cnPulse port 1) cnPulse derives power input from the radio or CMM port and returns the 1PPS signal and satellite statistics on port 1. Typically used on CMM5, cnReach and the AUX ports on PMP 450i, PMP450m or PTP 450i Mode 2: CambiumSYNC In-line mode (uses cnPulse port 2 and port 3) cnPulse is deployed in line with the radio’s CAT-5 drop cable. cnPulse receives power (and data) from the ODU’s PoE power injector on port 3. cnPulse port 2 then outputs PoE+Data+CambiumSYNC to the main input on a radio. Typically used on PTP 550.
