TimesProtect Surge / Lightning Arrestor 700-2700MHz, 4.3-10 Female to 4.3-10 Female

High-performance surge protector ensuring reliable RF system protection

This TimesProtect surge and lightning arrestor is designed for broadband RF applications from 700 to 2700 MHz. Featuring a DC-blocked design and excellent passive intermodulation performance, it safeguards equipment against multiple lightning strikes while maintaining outstanding RF characteristics and low insertion loss.

Key Features

• Broad frequency coverage: Operates from 700 to 2700 MHz, suitable for a wide range of wireless applications.
• Superior surge protection: DC-blocked circuit design withstands up to 50 kA surges, delivering reliable multi-strike performance.
• Excellent RF performance: Provides low insertion loss under 0.1 dB and VSWR better than 1.15:1 for efficient signal transmission.
• Low passive intermodulation: Achieves PIM performance better than -160 dBc, ensuring interference-free operation in sensitive systems.
• Rugged construction: Built with solid brass housing and IP67-rated weatherproofing for durability in outdoor and indoor installations.
• High power handling: Rated for up to 750 W average power, supporting demanding RF environments.
• Long service life: Designed for a minimum of 500 mating cycles with robust materials and plating.

Engineered to combine surge resilience with exceptional RF efficiency, this protector ensures safe and uninterrupted operation for critical communication systems.
