Teltonika RUTM52 Dual 5G Router
Teltonika RUTM52 Dual 5G Router
Compact, High-Performance Mobile Router for Industrial Applications
The Teltonika RUTM52 is a powerful and compact mobile router designed to deliver reliable internet connectivity in remote and industrial environments. With support for 4G LTE and Wi-Fi, this device provides high-speed data transfer and versatile connectivity options, ensuring seamless communication for a wide range of IoT and M2M applications. Whether used in fleet management, remote monitoring, or industrial automation, the RUTM52 is built to perform in challenging conditions while ensuring robust security and easy management.
This router is designed to meet the needs of businesses that require constant, high-speed connectivity on the move or in harsh environments. Its durability and compact design make it a great fit for mobile and fixed installations.
Key Features
- LTE Connectivity: With 4G LTE support, the RUTM52 ensures reliable, high-speed mobile internet access. It also supports fallback to 3G and 2G networks for continued connectivity in remote areas.
- Dual SIM Functionality: Features two SIM slots with automatic switching for enhanced reliability, ensuring that the router remains connected even if one network fails or experiences weak signal.
- Advanced Security: Built-in security features, including a firewall, VPN support, and secure remote management, protect against unauthorized access and cyber threats.
- Multiple Interfaces: The router includes 1 x WAN port, 4 x LAN ports, and additional digital inputs/outputs, offering flexibility for various devices and applications.
- Remote Management: The Teltonika RMS (Remote Management System) allows for easy monitoring, configuration, and firmware updates, reducing the need for on-site visits.
- Rugged Design: The RUTM52 is designed for industrial environments with an IP30 rating, ensuring durability in harsh conditions and maintaining reliable performance over time.
The RUTM52 is a versatile and rugged mobile router, ideal for industries where reliable, high-speed internet connectivity is essential. With its comprehensive features and ease of management, it’s a trusted solution for a variety of applications.
Product Specifications | |
---|---|
Mobile Module | 2 x 5G Sub-6 GHz SA/NSA 2.1/3.3Gbps DL (4x4 MIMO) 900/600Mbps UL (2x2 MIMO); 4G LTE DL Cat 20 2.0Gbps (4x4 MIMO)/UL Cat 20 200Mbps; 3G: 42 Mbps DL, 5.76Mbps UL |
3GPP Release | Release 16 |
eSIM | Consumer type eSIM, profile download and removal operations, up to 7 eSIM profiles; does not include data plans |
SIM Switch | 2 SIM cards, auto-switch for weak signal, data limit, roaming, network fail, SIM idle protection |
Status | IMSI, ICCID, operator, data connection state, network type, bandwidth, signal strength, SINR, and other network metrics |
SMS | Send/read SMS via HTTP POST/GET, SMS autoreply, SMPP, Email/SMS conversion, scheduled SMS |
USSD | Supports sending and reading Unstructured Supplementary Service Data messages |
Black/White List | Operator black/white list by country or separate operators |
Multiple PDN | Support for different PDNs for multiple network access |
Band Management | Band lock, used band status display |
SIM PIN Code Management | Enables setting, changing, or disabling the SIM card's PIN |
APN | Auto APN |
Bridge | Direct connection between mobile ISP and device on LAN |
Passthrough | Router assigns its mobile WAN IP address to another device on LAN |
Framed Routing | Support for IP network behind 5G UE |
Wireless Mode | 802.11b/g/n/ac Wave 2 (Wi-Fi 5) with MU-MIMO, up to 867 Mbps |
Wi-Fi Security | WPA2-Enterprise, WPA3, AES-CCMP, TKIP, EAP-TLS, 802.11w Protected Management Frames (PMF) |
SSID/ESSID | ESSID stealth mode |
Wi-Fi Users | Up to 150 simultaneous connections |
Wireless Connectivity Features | Wireless mesh, fast roaming, Relayd, radio resource measurement (802.11k) |
Ethernet WAN | 1 x WAN port 10/100/1000 Mbps |
Ethernet LAN | 4 x LAN ports, 10/100/1000 Mbps |
Routing | Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP), Policy-based routing |
VoIP Passthrough Support | H.323 and SIP-alg protocol NAT helpers |
Connection Monitoring | Ping Reboot, Wget Reboot, LCP and ICMP link inspection |
Firewall | Port forward, traffic rules, TTL target customization |
DHCP | Static and dynamic IP allocation, DHCP relay, server configuration |
QoS / Smart Queue Management | Traffic priority queuing, WMM, 802.11e |
Load Balancing | Balance Internet traffic over multiple WAN connections |
DDNS | Supports >25 service providers |
DNS over HTTPS | Secure DNS resolution via HTTPS |
VRF Support | Initial VRF support |
Traffic Management | Real-time monitoring, traffic usage history |
General Information | |
---|---|
Manufacturer: | Teltonika |
Manufacturer Part Number: | RUTM52 |
Barcode: | 90012283 |
Packaging Details | |
Weight: | 0.56 KGS |
Width: | 5.00 (cm) |
Height: | 10.00 (cm) |
Depth: | 14.00 (cm) |
