Milesight UF31 5G Modem

0 review Write a Review

The Milesight UF31 Ultra Fast 4G/5G Dongle with Compact Industrial-Grade Design, Outstanding Performance, Redundancy with 4G fail-over, Plug & Play Networking, Flexible Deployment Options and Remote Management on DeviceHub.

SKU: IOT-UR-00087

MPN: UF31-554AE

Shipping: Calculated at Checkout

$1,167.69 inc GST

$1,061.54 ex GST

Hurry up! Current stock:

Quantity:

Milesight UF31 5G Modem

$1,167.69 inc GST

$1,061.54 ex GST

Product Details
Specifications
Additional Information

Product Details

The Milesight UF31 5G Modem is a high-performance 5G modem for 5G wireless networking applications. It supports 5G NSA&SA, 4G LTE and 3G networks from telecom service providers of most countries in the world. The USB type-C port and Ethernet port are adopted to provide high-speed internet access for field devices. With a compact size and industrial design the UF31 is easy to carry out or embed to any equipment which is particularly suitable for smart offices, video surveillance, digital media implementations, industrial automation, traffic applications, robots and so on.

Features:

Support global 5G NSA&SA/4G LTE/WCDMA network, enables up to 2.5 Gbps download speeds.
Plug and play, provide lightning transmission via Gigabit Ethernet port or USB 3.0
Embeds hardware watchdog to automatically recover from various failure, ensure highest level of availability.
Wide operating temperature range from -20 to 50 degrees and industrial design for harsh environment.
USB or DC power supply optional.
Easy to deploy anywhere with compact size, suit for embedded installation.

Hardware System

Specification	Details
CPU	Quad-core ARM Cortex-A55, 2 GHz
Memory	1 GB LPDDR4X RAM and 1 GB NAND Flash

Cellular Interface

Specification	Details
Network	5G NR SA&NSA/4G LTE/WCDMA
Frequency	5G Sub-6: N1/N3/N5/N7/N8/N20/N28/N38/N40/N41/N77/N78/N79 LTE FDD: B1/B3/B5/B7/B8/B18/B19/B20/B28/B32 LTE TDD: B38/B40/B41/B42/B43/B46 WCDMA: B1/B5/B8
Antenna Connector	4 × 50 Ω SMA Connectors (Center PIN: SMA Female)
SIM Slot	1 (Micro SIM-3FF)

Ethernet Interface

Specification	Details
Numbers	1 × 10/100/1000 Mbps LAN Port
Mode	Full or Half Duplex (Auto-Sensing)

GNSS

Specification	Details
Antenna Connector	1 × 50 Ω SMA Connector (Center PIN: SMA Female)
Technology	GPS/GLONASS/Beidou/Galileo/QZSS

Others

Specification	Details
USB	1 × USB 3.0 (Type-C) for Power Supply, Network Supply and Debug
Reset Button	1 × RESET (Internal)
LED Indicators	1 × STATUS, 1 × Cellular Network
Built-in	Watchdog, Timer

Software

Specification	Details
Network Protocols	IPv4/IPv6, TCP, UDP, DHCPv4/DHCPv6, HTTP, HTTPS, DNS, ARP, Telnet, SSH, etc.
VPN	IPsec, OpenVPN
Security	Access Control, Port Mapping, DMZ, SYN-Flood Protection, Filtering (IP & MAC & Domain)
Management	Web, CLI, DeviceHub

Power Supply and Consumption

Specification	Details
Power Connector	2-pin 3.5 mm Terminal Block
Power Input	1. 5-24 VDC, with Surge-Protection and Reverse Polarity Protection 2. 5V/3A by USB Type-C Port
Power Consumption	Typical 3.9 W

Physical Characteristics

Specification	Details
Ingress Protection	IP30
Housing & Color	Metal, Black
Dimension	90 x 72 x 15 mm (3.54 x 2.83 x 0.59 in)
Installation	Desktop, Wall Mounting, DIN Rail Mounting

Environmental

Specification	Details
Operating Temperature	-20°C to +50°C (-4℉ to +122℉)
Storage Temperature	-40°C to +85°C (-40℉ to +185℉)
Ethernet Isolation	1.5 kV RMS
Relative Humidity	0% to 95% (Non-condensing) at 25°C/77℉

Approvals

Specification	Details
Regulatory	CE, FCC
Environmental	RoHS

Additional Information

Datasheet

General Information
Manufacturer:	Milesight
Manufacturer Part Number:	UF31-554AE
Barcode:	6974225039043
Packaging Details
Weight:	1.25 KGS
Width:	18.00 (cm)
Height:	28.00 (cm)
Depth:	6.00 (cm)
