Hikvision HiLook PTZ-N4215I-DE, 2MP PTZ Camera, 15X Zoom, IR 100m, F1.6 Aperture
Hikvision HiLook PTZ-N4215I-DE, 2MP PTZ Camera, 15X Zoom, IR 100m, F1.6 Aperture
The Hikvision HiLook PTZ-N4215I-DE is a powerful 2 MP network camera designed for clarity and precision. Equipped with DarkFighter technology, this camera provides vivid imaging in challenging lighting conditions. With a 120 dB Wide Dynamic Range (WDR), it excels in high-contrast scenes, balancing bright and dark areas to ensure clear and detailed visuals.
Key Features:
- 2 MP resolution with maximum 1920 × 1080 video quality
- 100 m IR range with smart IR for enhanced night vision
- 15x optical zoom and 16x digital zoom with 5 mm to 75 mm focal length
- 120 dB true WDR for clear imaging in challenging lighting
- IP66-rated for water and dust resistance, with 4000V surge protection
- 360° endless pan, -15° to 90° tilt, and speeds up to 80°/s
- H.265+ compression
- Smart event detection, including intrusion and line crossing
Pan, Tilt, and 15x Optical Zoom
This camera offers complete 360° endless pan, along with tilt capability from -15° to 90°, allowing for broad coverage and flexible positioning. Its 15x optical zoom enables close-up inspections without compromising image quality. Coupled with a 16x digital zoom, it provides extensive surveillance potential, making it ideal for large outdoor areas.
High-Efficiency H.265+ Video Compression
To optimise bandwidth and storage, the PTZ-N4215I-DE utilises H.265+ compression technology, significantly reducing data load while maintaining high-quality video. This compression capability is essential for prolonged recording and live monitoring, especially in high-traffic network environments.
Excellent Low-Light and Infrared Capability
The PTZ-N4215I-DE is engineered for nighttime performance, with enhanced IR illumination extending up to 100 metres. This ensures visibility even in complete darkness, with features like smart IR technology to avoid overexposure, making it a reliable choice for 24/7 surveillance.
Robust Protection and Durability
This model is built to withstand harsh weather conditions with its IP66 rating for water and dust resistance. It also includes lightning and surge protection, making it suitable for challenging outdoor environments where reliable performance is essential.
Intelligent Event Detection
Equipped with advanced motion and tampering detection, this camera supports smart events such as intrusion detection and line crossing detection. These intelligent functions help automate alerts and enable responsive security measures, allowing timely interventions.
Flexible Connectivity and Storage Options
The PTZ-N4215I-DE supports PoE (802.3at) for simplified installation, while also providing onboard storage options with a Micro SD slot, supporting up to 256 GB. This flexibility ensures compatibility with various network configurations and storage needs.
Category | Specification | Details |
---|---|---|
Model | PTZ-N4215I-DE | 4-inch 2 MP 15X Powered by DarkFighter IR Network Speed Dome |
Camera | Image Sensor | 1/2.8" progressive scan CMOS |
Resolution | Max. Resolution | 1920 × 1080 |
Illumination | Min. Illumination | Colour: 0.005 Lux @ (F1.6, AGC ON) B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR |
Lens | Focal Length | 5 mm to 75 mm 15x optical zoom |
Field of View (FOV) | Horizontal: 57.6° to 4.0° Vertical: 34.4° to 2.3° Diagonal: 64.5° to 4.6° |
|
Aperture | Max. F1.6 | |
Illuminator | Supplement Light Type | IR |
Range | Up to 100 m | |
PTZ | Movement Range (Pan) | 360° endless |
Movement Range (Tilt) | -15° to 90° (Auto-flip) | |
Pan Speed | Configurable, 0.1°/s to 80°/s, Preset Speed: 80°/s | |
Tilt Speed | Configurable, 0.1°/s to 80°/s, Preset Speed: 80°/s | |
Presets | 300 | |
Video | Main Stream | 50Hz: 25fps (1920×1080, 1280×960, 1280×720) 60Hz: 30fps (1920×1080, 1280×960, 1280×720) |
Sub-Stream | 50Hz: 25fps (704×576, 640×480, 352×288) 60Hz: 30fps (704×480, 640×480, 352×240) |
|
Compression | Video Compression | H.265+/H.265/H.264+/H.264 |
Network | Protocols | IPv4/IPv6, HTTP, HTTPS QoS, FTP, SMTP UPnP, SNMP, DNS DDNS, NTP, RTSP RTCP, RTP, TCP/IP UDP, IGMP, ICMP DHCP, PPPoE |
Audio | Audio Sampling Rate | AAC: 16 kHz MP2L2: 16 kHz MP3: 8 kHz, 16 kHz PCM: 8 kHz, 16 kHz |
Interface | Ethernet | 1 RJ45 10 M/100 M Ethernet PoE (802.3 at, class 4) |
Storage | On-board Storage | Supports Micro SD/SDHC/SDXC, up to 256 GB |
General | Power | 12 VDC, 2.0 A & PoE (802.3at), Max. 18 W |
Dimension | Ø 166 mm × 289.6 mm | |
Weight | Approx. 2.5 kg | |
Environment | Operating Conditions | -30 °C to 65 °C Humidity 90% or less (non-condensing) |
Protection | Rating | IP66 4000V Lightning Protection Surge Protection Voltage Transient Protection |
General Information | |
---|---|
Manufacturer: | HikVision HiLook |
Manufacturer Part Number: | PTZ-N4215I-DE |
Barcode: | PTZ-N4215I-DE |
Packaging Details | |
Weight: | 2.50 KGS |
Width: | 17.00 (cm) |
Height: | 29.00 (cm) |
Depth: | 17.00 (cm) |
