| Specification |
Details |
| Dimensions (W×D×H) |
260 mm × 140 mm × 30 mm (10.24 in. × 5.51 in. × 1.18 in.) |
| Weight |
0.48 kg |
| Wi-Fi Standards |
Wi-Fi 6 (802.11ax) |
| MIMO |
2.4 GHz, 2×2, MU-MIMO
5 GHz, 2×2, MU-MIMO |
| Max. Wi-Fi Speed |
2.4 GHz: 574 Mbps
5 GHz: 2402 Mbps |
| Channel Width |
2.4 GHz: Auto/20/40 MHz
5 GHz: Auto/20/40/80/160 MHz |
| Antennas |
5 (External Omnidirectional) |
| Antenna Gain |
2.4 GHz: 5 dBi
5 GHz: 5 dBi |
| WAN Port |
1×10/100/1000 Base-T |
| LAN Ports |
3×10/100/1000 Base-T |
| Recommended Users |
60 |
| Max. Users |
192 |
| Power Supply |
DC 12V/1.5A |
| Power Consumption |
< 18 W |
| Operation Frequency Bands |
802.11b/g/n/ax: 2.400 GHz to 2.483 GHz
802.11a/n/ac/ax: 5.150 GHz to 5.350 GHz
802.11a/n/ac/ax: 5.470 GHz to 5.725 GHz, 5.725 GHz to 5.850 GHz |
| DFS |
Yes |
| Transmit Power |
CE EIRP: ≤20dBm (2.4GHz), ≤27dBm (5GHz), ≤20dBm 2400~2483.5MHz
Myanmar: 2400~2483.5MHz ≤ 20dBm(EIRP); 5150~5350MHz ≤ 23dBm(EIRP); 5470~5725MHz ≤ 30dBm(EIRP); 5725~5850MHz ≤ 30dBm(EIRP) |
| Receive Sensitivity |
2.4 GHz:20MHz
802.11b: -91 dBm(1 Mbps)
802.11g: -91 dBm(6 Mbps), -72 dBm(54 Mbps)
802.11n: -90dBm(MCS0), -70 dBm(MCS7)
5 GHz:20MHz
802.11n: -85 dBm(MCS0), -67 dBm(MCS7)
802.11a: -89 dBm(6 Mbps), -72 dBm(54 Mbps)
802.11ac: -90dBm(MCS0), -63dBm(MCS8)
802.11ax: -88dBm(MCS0), -62dBm(MCS8), -58dBm(MCS11) |
| Operating Temperature |
-10 °C to +40 °C (14 °F to 113 °F) |
| Operating Humidity |
5% to 95% Noncondensing |
| Wireless Features |
OFDMA, MU-MIMO, BSS Coloring, Maximum Number of SSIDs 6, SSID Hiding, Band Steering, Guest Wi-Fi, WPA/WPA2, WPA3, Layer 2 Roaming, Blacklist, Reyee Mesh, Mesh Pairing by Hardware, Mesh Pairing by Mesh Button, Mesh Pairing by Eweb, Recommended Hop Count ≤5 |
| Wi-Fi Optimization |
QoS (WMM), WPS, Transmission Power Adjustment |
| Hardware |
CPU: MT7981
Flash: 128 MB
RAM/SDRAM: 256 MB
Color: Black
System LED Indicator: Yes
Reyee Mesh LED Indicator: Yes
Reyee Mesh Button: Yes
Power Button: No
Reset Button: Yes
DC Connector Dimensions: Outer Diameter: 5.5 mm, Inner Diameter: 2.1 mm, Length: 9.5 mm |
| WAN Features |
Static IP, DHCP, PPPoE, Learning PPPoE Account & Password, VLAN Tagging |
| Wireless Features |
DHCP Server, Client List, Static IP Assignment, Port-Based Flow Control, TR069, IPv6, DDNS, IPTV, Alarm, Diagnosis, UPnP, ARP Binding, Port Mapping, DMZ Host, Rate Limitation of Terminals, Hardware Acceleration, MAC Address Cloning, Cloud Management, Repeater Mode, WISP Mode |
| Security |
PPTP VPN Server, PPTP VPN Client, L2TP VPN Client, Parental Control Time Schedule, Protect TCP Flood Attacks, Protect ICMP Attacks, Protect UDP Flood Attacks |
| System |
Default Access/Password: 192.168.110.1, No Password Required by Default
URL Access, Local Upgrade, Online Upgrade, APP Upgrade, Syslog, Backup, Factory Reset
Language: Chinese, English, Vietnamese, Turkish, Indonesian, Thai, Traditional Chinese, Spanish, Russian, Arabic, Ukrainian, Czech, Italian |
| Package Contents |
Wireless Router 1
Power Adapter 1
Quick Installation Guide 1
Cat5E UTP Cable 1
Warranty Card 1 |
