EZVIZ
This smart entry kit combines the EZVIZ EP3X Pro dual-lens video doorbell with a smart keypad lock and plug-in chime for complete front-door access and surveillance. Featuring a 2K main camera and 1080p downward lens, it delivers clear coverage of both visitors and packages. Built-in 32GB eMMC storage, AI detection, and secure PIN access ensure wire-free, subscription-free protection with flexible entry control.
With high-resolution video, secure PIN access, and no recurring costs, this kit offers a streamlined solution for modern front-door control and visibility.
Product Specifications | |
---|---|
Model | CS-EP3x Pro + CH1 + Solar Panel |
Main Camera Resolution | 2K (2048 × 1296) |
Bottom Camera Resolution | 1080p (1920 × 1080) |
Field of View | Front: 162° / Bottom: 155° |
Night Vision | Color night vision up to 6 m |
AI Detection | Human and package detection with custom zones |
Access Methods | Keypad PIN access, EZVIZ App, Two-way talk |
Storage | Built-in 32GB eMMC (local), EZVIZ CloudPlay optional |
Battery Capacity | 5,200 mAh rechargeable lithium |
Power Options | Solar panel, battery, or 8–24 VAC wired |
Chime Power | 100–240 V AC (plug-in) |
Audio Features | Two-way talk, voice changer, tamper siren |
Connectivity | Wi-Fi 2.4 GHz (802.11 b/g/n), dual antenna |
Weatherproof Rating | IP65 (doorbell and solar panel) |
Operating Temperature | -20°C to 50°C |
Doorbell Dimensions | 166 × 50 × 31 mm |
Chime Dimensions | 101 × 64 × 32 mm |
Solar Panel Dimensions | 126 × 56 × 44 mm |
Certifications | CE, REACH, WEEE, RoHS |
